5MP OV5640 Camera Module USB FOV 60°/70°/100°/110°/120°/160°
The camera module has a 5 Mega Pixel resolution (2592×1944) with an Omnivision OV5640 CMOS image sensor. The OV5640 (color) image sensor is a low-voltage, high-performance.
| NO | Item | Specification |
| 1 | Module No. | VM-D5640H |
| 2 | Image Sensor | 1/4 Inch OV5640 |
| 3 | Pixel Size | 1.4 µm x 1.4 µm |
| 4 | FOV | 60°/70°/100°/110°/120°/160° |
| 5 | Color | RGB |
| 6 | Effective Pixel | 2592 x 1944 (5MP) |
| 7 | Output Format | MJPEG, YUY2 |
| 8 | Support Resolution and Frame Rate | MJPG: 2592 x 1944 @ 15FPS 640*480@ 30FPS YUY2: 2592 x 1944 @ 2FPS 640*480@ 30FPS |
| 9 | Focal Length | 60°: 2.8mm 100°: 2.1mm 160°: 1.66mm |
| 10 | Object Distance | 60cm (Customizable) |
| 11 | Focus | Fixed Focus/Auto Focus/Manual Focus |
| 12 | Interface | USB2.0 |
| 13 | Controllable Parameters | Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White Balance, Backlight Contrast, Exposure |
| 14 | Working Temperature | -20℃ ~ 70℃ |
| 15 | Voltage | DC 5V |
| 16 | Module Size | 26.2*12.7mm |
| 17 | System Support | Win XP/Vista/Win7/Win8 / Linux with UVC (above linux-2.6.26) MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC |
Check more info on the OV5640 sensor
